$1,454.99
Quantities and pricing are subject to change and may be subject to a PDI charge
Stock: 28
Call us at 1.866.344.SAWS (7297) for more info.
Contact Woodsman Equipment to check this product's availability.
| Engine | 20" RSN 3/8" 1,5 mm C85 SKU: 965 96 83‑09 | 24" RSN 3/8" 1,5 mm C85 SKU: 965 96 83‑12 | 16" RSN 3/8" 1,5 mm C85 SKU: 965 96 83‑18 | 18" RSN 3/8" 1,5 mm C85 SKU: 965 96 83‑20 | 28" RSN 3/8" 1,5 mm C85 SKU: 965 96 83‑21 |
|---|---|---|---|---|---|
Chain speed at max power | 22.7 m/s | 22.7 m/s | 22.7 m/s | 22.7 m/s | 22.7 m/s |
Cylinder displacement | 70.7 cm³ | 70.7 cm³ | 70.7 cm³ | 70.7 cm³ | 70.7 cm³ |
Output shaft power | 4.1 kW | 4.1 kW | 4.1 kW | 4.1 kW | 4.1 kW |
| Equipment | |||||
Recommended bar length, min | 40 cm | 40 cm | 40 cm | 40 cm | 40 cm |
Pitch | 3/8" | 3/8" | 3/8" | 3/8" | 3/8" |
Recommended bar length, max | 70 cm | 70 cm | 70 cm | 70 cm | 70 cm |
Chain type | H42 | H42 | H42 | H42 | H42 |
Bar length | 50 cm | 60 cm | 40 cm | 45 cm | 70 cm |
Bar length (inch) | 20 in | 24 in | 16 in | 18 in | 28 in |
| Dimensions | |||||
Weight (excl. cutting equipment) | 6.6 kg | 6.6 kg | 6.6 kg | 6.6 kg | 6.6 kg |
| Sound and noise | |||||
Sound pressure level at operators ear | 110 dB(A) | 110 dB(A) | 110 dB(A) | 110 dB(A) | 110 dB(A) |
Sound power level, guaranteed (LWA) | 119 dB(A) | 119 dB(A) | 119 dB(A) | 119 dB(A) | 119 dB(A) |
| Vibration | |||||
Equivalent vibration level (ahv, eq) rear handle | 8 m/s² | 8 m/s² | 8 m/s² | 8 m/s² | 8 m/s² |
Equivalent vibration level (ahv, eq) front handle | 5.7 m/s² | 5.7 m/s² | 5.7 m/s² | 5.7 m/s² | 5.7 m/s² |
| Emission | |||||
Exhaust emissions (CO₂ EU V) | 742 g/kWh | 742 g/kWh | 742 g/kWh | 742 g/kWh | 742 g/kWh |
