HONDA GENERATOR 5000 WATT

$2,986.00

Quantities and pricing are subject to change and may be subject to a PDI charge

Stock: 0

The EB5000X3CT2 has premium features for industrial usage and general purpose applications in commercial and rental situations.

https://powerequipment.honda.ca/en/generators/work-industrial/models?trim=commercial_5000_gfci_10444

Request Information

  • This field is for validation purposes and should be left unchanged.

Call us at 1.866.344.SAWS (7297) for more info.

Contact Woodsman Equipment to check this product's availability.

SKU: EB5000X3C

Dual voltage power with premium features and GFCI (Ground Fault Circuit Interrupter) protection on duplex receptacles

5,000 watts maximum AC output

Powerful, easy-start Honda iGX390 commercial-grade engine

Auto-throttle further extends running time by automatically adjusting engine speed to idle when under no load

Standard wheel kit with positive lock folding handles for easy transportation and convenient, compact storage

Cold Climate TechnologyTM aids continuous running in cold weather conditions

Honda exclusive iAVR (Intelligent Auto Voltage Regulation) system for stable power delivery and available extra wattage (7,000 watts for 10 seconds to start larger equipment)

Voltage Selector Switch allows both 120 V and 240 V output, or total generator output to be available through any of the 120 volt outlets, limited only by the capacity of the individual outlet for powering devices with larger wattage requirements.

Hanger kit/lifting eye for easier moving around the job site

Electrical

Generator Type

Brush type

Maximum AC Output (Watts)

5,000

AC Voltage Available

120 / 240

Maximum Continuous AC Output (Watts)

4,500 7,000 (iAVR)

Max. Rated AC Amperage @ 120 V / 240 V

37.5 / 18.8 (58.3 / 29.2 for 10 sec. iAVR)

Ground Fault Circuit Interrupter (GFCI)

Standard

Frequency (Hertz)

60

Automatic Voltage Regulator

Standard iAVR (Intelligent Automatic Voltage Regulator)

DC Output Volts / Amps

N/A

Common Duplex Receptacle Specifications

37.5 amps/120 VAC continuous is available as combined total from these twin duplex AC receptacles. Maximum of 18.8 amps available from each GFCI duplex receptacle.

DC Receptacle Specifications

N/A

DC Charging Cable

N/A

High Capacity 120 / 240 VAC Twist Lock Receptacle Specifications

This receptacle (NEMA # L5-30R) will supply 30 amps at 120 VAC continuously. This receptacle (NEMA # L14-30R) will supply 18.8 amps (4.5 kVA) at 240 VAC continuously.

Engine

Engine Type

Honda iGX390T2 OHV, 4-stroke, air-cooled

Displacement

389 cc

Starting System

Manual recoil

Low Level Oil Alert System

Standard

Auto Throttle

Standard

Remote Start Capability

No

Fuel Tank Capacity

23.5 litres (5.17 Imp. gal.)

Additional Information

Transport Wheels

2 Wheel standard

Lifting Hook

Standard

Battery

N/A

Approximate Running Time (hrs.) / Tankful

8.1** / 11.2****

Rated Fuel Consumption (litres/hr)

2.90**

Noise Level dB(A) (1.5 m to 7 m)

72**

Length (Without Handles and Wheels)

681 mm (26.8 in.)

Length (With Handles and Wheels)

1,043 mm (41.1 in.)

Width (Without Handles and Wheels)

530 mm (20.9 in.)

Width (With Handles and Wheels)

706 mm (27.8 in.)

Height (Without Lift-Hook)

719 mm (28.3 in.)

Height (With Lift-Hook)

773 mm (30.4 in.) standard

Dry Weight

94.6 kg (208.6 lbs.)

Cold Climate Technology

Standard
